KRANZLE Therm 635-1, Therm 895-1, Therm 1165-1 Switch Box
Genuine Spare Parts
See Diagram & Click the link for price & availability
1. Electrical box 448071
2.1 Cover for electrical box therm 635-1 470145
2.2 Cover for electrical box therm 875-1 470142
2.3 Cover for electrical box therm 895-1 470143
2.4 Cover for electrical box therm 1165-1 470144
3. Front panel manometer 443751
6. Bracket for switch 44810
8. Bracket thermostat 47012
9. Gasket for thermostat 47013
13. Gasket for overtemperature cover 441821
14. Control unit for control board 44257
15. Cover for overtemperature release 44361
16. Control board for overtemperature release 44370
19. Grounding terminal 44839
21. Washer 4.3 DIN9021 43472
22.1 Control board therm 400 V / 50 Hz/60 Hz 44359
22.2 Control board 230 V / 50 Hz/60 Hz (therm 635-1) 443591
23.1 Contactor 400 V / 50 Hz/60 Hz 460051
23.2 Contactor 230 V / 50 Hz/60 Hz (therm 635-1) 46005
24. Screw 4.0 x 25 with molded washer 43425
25.1 Overcurrent release 8.5 A 3-pole (therm 875-1) 426412
25.2 Overcurrent release 11.3-16A 42641
26. Cable horn with strain relief 448191
29.1 Mains connection cable three-phase 8.0m, 4x 1.5 mm² 44036
29.2 Mains connection cable with plug 5.75 m, 3 x 1.5 mm²
(therm 635-1) 41092 New P/No. 43459
30. PG16 fitting 1 bushing 414191
31. PG16 fitting 2 bushings 44132
32. PG16 fitting 3 bushings 44133
34. Fuel pressure gauge with bracket 443620
35. Connector R1/4" female thread DN-6 elbow 44409
36. Sealing ring 8.3 x 11.3 x 2 132751
37. Miniature fuse 1.25 A slow-blow 44676
38. Miniature fuse 2.00 A slow-blow 448891
39. Miniature fuse 630mA slow-blow 442002
40. Retaining bridge 44352
42. Miniature fuse 32 mA slow-blow 442001
45. Feedthrough grommet for capillary tube 44823
47. Gasket for electrical box 44838
48. Clamp for pressure gauge 44049
49. Connection sleeve for pressure gauge 44136
50. Cover for electrical box 47015
55. Pressure measuring line 441021
-
