KRANZLE E-Therm 500 M 24kW, 603 M 36kW, 873 M 48kW Switch Box 1
Genuine Spare Parts
See Diagram & Click the link for price & availability
1. Electrical box 448071
2. Cover for electrical box therm 470141
3. Front panel manometer 448092
4. Cable reel cover 48911
6. Bracket for switch 44810
8. Bracket for thermostat 47012
9. Gasket for thermostat 47013
13. Gasket for overtemperature cover 441821
14. Control unit for control board 44257
15. Cover for overtemperature release 44182
19. Grounding terminal 44839
21. Washer 4.3 DIN 9021 43472
22. Control board 400 V / 50/60 Hz electrically heated 447704
23. Contactor 400 V / 50/60 Hz 23 A 444004
24. Screw 4.0 x 25 with crimped Washer 43425
25. Overcurrent release 3-pole 11.3-16A 426412
26. Cable horn with strain relief 44819
30. PG16 gland 1 feedthrough 414191
31. PG16 gland 2 feedthroughs 44132
32. PG16 gland 3 feedthroughs 44133
45. Feedthrough grommet for capillary tube 44823
47. Gasket for electrical box 44838
48. Clamp for pressure gauge 44049
49. Connection sleeve for pressure gauge 44136
50. Electrical box cover 47015
55. Pressure measuring line 441021
57. Retaining bridge 44352
58. 630 mA slow-blow fuse 442002
59. 2.0 A slow-blow fuse 448891
60. 1.25 A slow-blow fuse 44676
61. 32 mA slow-blow fuse 442001
-
