KRANZLE Therm 715, Therm 1017 Assembly
Genuine Spare Parts
See Diagram & Click the link for price & availability
1. Cockpit 443511
2. Fuel tank 442681
3. Gray water tank 44009
5. Lance quivers 440081
13. Tank cap with O-ring 442700
14. Chassis 44001
15. Front bar 44002
17. Railing 440161
20. O-ring 442710
22. Allen screw 44033
24. Screw 12150
28. Fuel tank drain plug 440041
31. Gasket for drain plug 410471
32.1 AC mains connection cable (therm 715) 41092
32.2 Mains connection cable, three-phase current (therm 1017) 44036
8.0 m, 4x 1.5 mm², H07RNF
33. Screw 434231
34. Fuel sieve 442690
37. High-pressure hose NW8 10m 44878
37.1 High-pressure hose NW8 20m (hose drum) 44877
38. O-ring 13273
39. Starlett II pistol with plug-in coupling 123272
40.1 Lance cpl. with flat jet nozzle D25045 (therm 715) 1 12420-D25045
40.2 Lance cpl. with flat jet nozzle D4006 (therm 1017) 1 12420-D4006
41. Lance holder left for Kränzle therm 44412
42. Lance holder right for Kränzle therm 44411
43. Screw 42647
-
Download Documents
Downloads for this product are currently unavailable, please get in contact if you require any documentation.
