KRANZLE Therm C 15/150 Compact Pressure Washer order no. 41.440
The C 15/150 is an excellent compact design, and a powerful hot and cold pressure washer running on 3-Phase power supply 415 volt. Durable design for industrial and commercial use.
Intergrated trolley takes steps and rough ground in its stride with large wheels with wide solid rubber tyres
7.5m power lead with cable reel
Storage for trigger gun with safety catch and lances
Shock absorbing buffers, front and rear
Technical Data:
Operating pressure bar (MPa): 30-150 (3-15)
Max admissible overpressure bar (MPa): 170 (17)
Water output l/min (l/h): 15 (900)
Inlet water temperature max °C: 60
Hot water output temp °C: 12-80
Steam level max °C: 150
Nozzle size: 055
Heating oil consumption max heating output kg/h (l/h): 6.0 (7.1)
Heating oil consumption 45°, kg/h (l/h): 4.3 (5.1)
Heating output Kw: 65
Fuel tank capacity monitoring: 25
Motor speed (rpm): 1400
Connected load V / A / Hz: 400 / 8.7 / 50
Power intake (kW): 4.8
Power output (kW): 4.0
Weight (kg): 179
Dimensions (L x W x H) in mm: 790 x 590 x 980
Features & Equipment:
Total-Stop system with delayed motor cut-out
Additional electrical over-current protection
Water flowing monitoring
Pre-aeration of combustion chamber
Visual flame monitoring
Safety thermostat triggers at emission temperatures above 230 °C
4-way safety system with overload protection
High fuel cut off for burner
High pressure detergent
10m Twin steel braided hose
One piece M2000 trigger gun with safety catch, stainless steel lance and flat jet nozzle
Parking brake
Water inlet-filter
Alternative part numbers :- 41440, 41440.0, 41.440.0
-
