• KRANZLE Therm C 11/130 Compact Pressure Washer order no. 41.442


    The CA 11/130 is an excellent compact design, and a powerful hot and cold pressure washer running on 240 volt Durable design for industrial and commercial use.

    Intergrated trolley takes steps and rough ground in its stride with large wheels with wide solid rubber tyres

    5m power lead with cable reel

    Storage for trigger gun with safety catch and lances

    Shock absorbing buffers, front and rear


    Technical Data:

    Operating pressure bar (MPa): 30-130 (3-13)

    Max admissible overpressure bar (MPa): 145 (14.5)

    Water output l/min (l/h): 11 (660)

    Inlet water temperature max °C: 60

    Hot water output temp °C: 12-80

    Steam level max °C: 140

    Nozzle size: 045

    Heating oil consumption max heating output kg/h (l/h): 5.1 (6.1)

    Heating oil consumption 45°, kg/h (l/h): 3.2 (3.8)

    Heating output Kw: 55

    Fuel tank capacity monitoring: 25

    Motor speed (rpm): 1400

    Connected load V / A / Hz: 230 / 15.0 / 50

    Power intake (kW): 3.4

    Power output (kW): 2.3

    Weight (kg): 179

    Dimensions (L x W x H) in mm: 790 x 590 x 980


    Features & Equipment:

    Total-Stop system with delayed motor cut-out

    Additional electrical over-current protection

    Water flowing monitoring

    Pre-aeration of combustion chamber

    Visual flame monitoring

    Safety thermostat triggers at emission temperatures above 230 °C

    4-way safety system with overload protection

    High fuel cut off for burner

    High pressure detergent

    10m Twin steel braided hose

    One piece M2000 trigger gun with safety catch, stainless steel lance and flat jet nozzle

    Parking brake

    Water inlet-filter



    Alternative part numbers :- 41442, 41442.0, 41.442.0
