KRANZLE Therm 601 E-ST 24 kW Static Pressure Washer

  • KRANZLE Therm 601 E-ST 24 kW Static Pressure Washer order no. 41.358 6



    Electrically heated Therms are unique to the market, allowing for constant operational temperature control within +/- 1°C and absolutely no pre-heating time required. Kranzle Therm E-ST series machines are an excellent modern sleek stainless steel design, a good size and fantastic quality, exactly what you'd expect when they are built to order. The Therm is a big, solid and very well made machine that weighs over 130 kgs.It is a powerful instant hot and cold pressure washer. Durable design for industrial and commercial use, best suited for factory use.

    Housing made of stainless steel

    Coin checking device and remote control for various cleaning programs (optional extra)

    3m power lead without plug

    Stainless steel lance with flat jet nozzle

    Electrical flow heater

    Total-stop system with delayed motor cut-out

    Additional electrical over-current protection

    Water flow monitoring

    4-way safety system with overload protection

    Operating hours meter

    High pressure detergent

    Automatic hose reel for up to 28m steel braided high pressure hose (optional extra)

    Instant hot water use with no pre-heating required



    Technical Data:

    Power supply: 3 Phase

    Operating Pressure (nozzle size 045): 30-100 bar / 3-10 MPa

    Water output (nozzle size 045): 10 l/m (600 l/h)

    Hot water output: 47 °C

    Heating output: 24 kW

    Motor speed: 1400 rpm

    Connected load: 41.2 A, 50 Hz

    Wattage / fuse: 26.6 kW / 63 A

    Weight: 130kg



    Nozzle size 035 available (please note 045 nozzle will be as standard with this machine unless requested on purchase):

    Operating Pressure (nozzle size 035): 30-160 bar / 3-16 MPa

    Water output (nozzle size 035): 8.6 l/m (516 l/h)

    Hot water output temperature (nozzle size 035): 52 °C



    Equipment:

    10m steel braided hose

    Trigger gun starlet with safety catch

    Flat jet lance



    Alternative part numbers :- 413586, 41358.6, 41.358.6
