KRANZLE Therm 1525-1 T Pressure Washer order no. 41.348 1
Therm 1525-1 T is an excellent design, to appreciate the size and quality of the Therm it really needs to be seen. The Therm is a big, solid and very well made machine that weighs over 200 kgs.It is a powerful hot and cold pressure washer running on 3-Phase power supply (415 volt). Durable design for industrial and commercial use.
Intergrated trolley takes steps and rough ground in its stride with large wheels with wide solid rubber tyres
Intergrated hose drum with foldable crank
7.5m power lead with cable reel
Storage for trigger gun with safety catch and lance
Technical Data:
Operating pressure bar (MPa): 30-125 (3-12.5)
Max admissible overpressure bar (MPa): 140 (14)
Water output l/min (l/h): 25 (1500)
Inlet water temperature max °C: 60
Hot water output temp °C: 12-65
Steam level max °C: 140
Nozzle size: 20125
Heating oil consumption max heating output kg/h (l/h): 7.7 (9.2)
Heating oil consumption 45°, kg/h (l/h): 7.2 (8.5)
Heating output Kw: 84
Fuel tank capacity monitoring: 35
Motor speed (rpm): 1400
Connected load V / A / Hz: 400 / 12 / 50
Power intake (kW): 7.5
Power output (kW): 5.5
Weight (kg): 228
Dimensions (L x W x H) in mm: 1050 x 800 x 1015
Features & Equipment:
Total-Stop system with delayed motor cut-out
Additional electrical over-current protection
Water flowing monitoring
Pre-aeration of combustion chamber
Visual flame monitoring
Safety thermostat triggers at emission temperatures above 230 °C
4-way safety system with overload protection
High fuel cut off for burner
Operating hours meter
High pressure detergent
Hose drum
20m Steel braided hose
Starlet trigger gun with safety catch
Stainless steel lance with flat jet nozzle
Parking brake
Water inlet-filter
Alternative part numbers :- 41348 1, 41348.1, 41.348.1
-
