• KRANZLE Quickly Unloader

    Genuine Spare Parts

    See Diagram & Click the link for price & availability

    1. Valve housing 12mm 497060

    2. Valve plug 497013

    3. O-ring 43058

    6. Sealing plug 13158

    7. Set screw 497015

    8. Ball 4.0 mm stainless steel 13472

    9. O-ring 150051

    10. Parbaks for 14mm bore 141231

    11. Control piston 497012

    12. Parbaks for spindle 6 mm 141232

    13. Piston guide 6 mm 496024

    14. Compression spring 14124

    15. Spring compression nut 492430

    16. Clear water filter with filter 13311

    17. High pressure seal 49226

    18. Spacer ring 12 mm Quickly with support 497011

    20. Brass sleeve with Teflon seat 12127

    21. Control piston engine shutdown 497029

    23. Plug 133851

    24. Compression spring 40520

    25. Support washer 150151

    26. O-ring 121362

    27. O-ring 12136

    28. Guide part control plunger 497027

    29. O-ring 43445

    30. Allen screw 46025

    32. Valve plunger / check valve 497022

    34. O-ring 40016

    35. Output piece M22 x 1.5 without injector 497016

    40. Hex Nut 12138

    52. O-ring 15017

    60. Housing for electrical switch 15204

    61. Rubber sleeve 15202

    63. Union nut 15203

    64. Cable 150191

    65. Sheet metal screw 15024

    66. Electric switch cover 15201

    67. O-ring 15023

    68. Micro switch 15018

    69. Cylinder screw 15025

    71. Repair kit for valves 497051

    72. Pressure switch cpl. 497035

    73. Valve housing complete. (Item 1-Item 35) 497059

    74. Rep set of cuffs 497064
