KRANZLE Profi 160 TST Valve Housing

KRANZLE Profi 160 TST Valve Housing

Seen it Cheaper?

KRANZLE Profi 160 TST Valve Housing

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Valve housing 404511

2. O-ring 41716

3. Valves (green) 417151

4. O-ring 13150

5. Valve plug 41714

5.1 Valve plug with R1/4" 42102

7. Hexagon screw 43832

8. Suction Ring 43825

9. Water filter 410462

11. Plug-in coupling R3/4“ 410472

13. Fabric cuff 410131

14. Backring 18 mm 410142

15. O-ring 40026

16. Leakage ring 18 mm 41066

18. Sleeve 410132

20. Intermediate ring 18 mm 410152

21. Aluminum sealing ring 13275

23. Pressure ring 41018

25. O'ring 12256

26. Stainless steel seat 14118

27. Snap ring 13147

28. Ermetoni nipple 41042

29. Copper ring 42104

30. Sealing plug R1/4" with collar 42103

31. Sealing plug 13385

32. Sealing plug 13158

33. Output part 40522

34. Stainless steel ball Ø10 12122

35. Check spring 141201

37. O-ring 40016

38. Basic part angle valve 466001

39. Valve needle 46601

40. Parbaks 6mm 46606

41. Guide part 46602

42. Handwheel 46603

43. Screw 46604

44. Suction pin 13236

45. Washer brass 43045

46. Chemical valve 46615

Repair Kits:

50. Repair kit for cuffs 18 mm without brass parts 410491

51. Repair kit for valves for APG pump 417481

52 Repair kit for ball check valve 40491
