KRANZLE Medium Quadro 599/799/899 TST Hose Drum

KRANZLE Medium Quadro 599/799/899 TST Hose Drum

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Side shell 46201

3. Drum part 46202

5. Allen screw 40313

6. Bearing block with brake 403271

7. Bearing block left 403051

8. Clamping piece 403071

9. Screw 43018

10. Drive shaft 40328

11. Wave water flow 462033

12. Elastic Stop Nut 40111

13. Foldable hand crank 403200 (Discontinued)

13. Foldable hand crank 403201

15. Disc 40181

16. Shaft retaining ring 22 mm 40117

17. Shaft retaining ring 16 mm 40182

18. Washer 50189

19. Locking disk 40325

20. Parbaks 16 mm 13159

22. Screw 43021

23. Swivel joint 40167

24. Connection part 40308

25. Spacer ring 40316

27. O-ring 41521

33. O-ring 13386

34. Plugs 13385

40. Union nut 132762

42. O-ring 13273

44. Connecting hose 46037

45. High-pressure hose NW6 20 m 434161

quadro 599, 799 TST

45.1 High pressure hose NW8 15 m 44879

quadro 899 TST

Hose drum complete without hose 46081

consisting of items 1 - 42
