KRANZLE Medium Quadro 599/799/899 TST Dirt Killer

KRANZLE Medium Quadro 599/799/899 TST Dirt Killer

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Spray body 41520

2. O-ring 41521

3. Nozzle seat 41522

4.1 Nozzle 035 (quadro 599) 415231

4.2 Nozzle 045 (quadro 799) 415236

4.2 Nozzle 06 (quadro 899) 415235

5. Stabilizer 41524

6. O-ring 13150

7. Spray plugs 41526

11. Front cap for dirt killer 415281

12. Rear cap for dirt killer 042 415402

19. Piercing nipples D12 13474

20. Pipe 965 mm, R1/4“ on both sides 13519

21. Handle shells left, right 12406

22. Screw 44525

Rep. set dirt killer 035 (quadro 599)

consisting of 1x item 2, item 3, item 4, item 5 410970

Repair set dirt killer 045 (quadro 799)

consisting of 1x item 2, item 3, item 4, item 5 410965

Repair set dirt killer 06 (quadro 899)

consisting of 1x item 2, item 3, item 4, item 5 410962

Dirt killer 035 for quadro 599 TST 12425-035

Dirt killer 045 for quadro 799 TST 12425-045

Dirt killer 06 for quadro 899 TST 12425-06
