• KRANZLE 1050 TS/TST Motor

    Genuine Spare Parts

    See Diagram & Click the link for price & availability

    1. Motor 230V / 50 Hz complete without electrics 49260

    4. Hood air duct 49283

    5 Motor bearing B-side 49288

    6 Motor bearing A-side 41027

    7 Oil seal 41024

    8 Fan wheel 49281

    9 Shaft retaining ring 49282

    10 Stator bearing bolt 49284

    11 Rubber seal 49287

    12 Fan terminal 3-pol. 43326

    13 Switch box lower part 491041

    14 On-off switch 49112

    15 Power cable grommet 49115

    16 Pressure switch cable grommet 491151

    17 Stator rubber mount 49285

    18 Capacitor 35µF 411144

    19 Power connection cable for 3 x 1.0 mm² (GB) 49121

    21 Screw 43415

    22 Allen screw 44831

    24 Lens screw 43470

    25 Cover for control box 49105

    26 Gasket for cover 49113

    27 Screw 43018

    28 Cable overcurrent release 49126

    29 Overcurrent release 1-pole 491250

    30 Screw 44234

    31 Serrated lock washer 43471

    41 Switch box complete 49150 (Items 11 - 15, 1 8, 21, 22, 25 - 27)
