KRANZLE 1050 TS/TST Unloader
Genuine Spare Parts
See Diagram & Click the link for price & availability
9. Stainless steel seat 14.118
11. Start-up relief valve 49.041 1
12. Stainless steel spring 49.042
13. Locking screw 49.04 3
14. control pistons 6 mm for AZC with seals 49.243 1
15. Parbaks for piston 14 mm 14.123 1
16. Parbaks for spindle 6 mm 14.123 2
18. Piston guide 6 mm 14.130 1
20. Spring black for AZ pump 43.046
21. Spring compression nut 49.243 0
49. Compression spring 40.520
50. O-ring 12.136
51. Guide part control plunger 49.058 0
52. O-ring 15.017
53. O-ring 43.445
54. Parbaks 4 mm 12.136
55. Support washer 15.015 1
57. Control plunger long 15.010 2
58. Parbaks 10 mm 15.013
59. Plug 13.385 1
60. Housing for electrical switch 15.204
61. Rubber sleeve 15.202
62. Hexagon nut 12.138
63. Union nut 15.203
64. Cable 49.023
65. Screw 15.024
66. Electric switch cover 15.201
67. O-ring 15.023
68. Micro switch 15.018
69. Cylindrical screw 15.025
71. Rep. -sentence Pressure switch mechanism 15.009 3
72. Pressure switch cpl. without mechanics 49.054
73. Valve housing cpl. for K1050 TST 49.152 2
73.1 Valve housing cpl. for K1050 without hose reel 49.152 1
74. Rep. set unloader valve 49.2440
-
Download Documents
Downloads for this product are currently unavailable, please get in contact if you require any documentation.
