KRANZLE Therm-RP 1200, 1400, 1600 Fuel Supply

KRANZLE Therm-RP 1200, 1400, 1600 Fuel Supply

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Fuel supply cover 44011

2. Flange with fuel lines 440101

3. Rubber seal 44012

4. PA hose DN6 0.22m 44403

5. Float switch 44014

7. Fuel line pump 441081

8. PA hose DN6 0.84m 44403

9. PA hose DN6 0.32m 44403

10. Connector angle 44405

11. Screw 414141

12. Connector socket 44407

13. Ermeto screw connection 44372

14. Connector angle 44408

16. Fuel filter connection part 44214

17. Rubber seal 3/4" 410471

18. Filter base body 13301

19. O'Ring 133031

20. Fuel filter sieve body 44213

21. Filter cup 133021

22. Screw-in elbow R1/4" AG x 10L 401211

23. Fuel pump with solenoid valve 44073

24. PA hose DN6 0.93m 44403

25. Coil for solenoid valve 442511

26. Solenoid valve 44251

27. Spacer pipe 128mm 44084

40. Fuel pump cpl. 44371

41. Fuel filter complete 44391
