KRANZLE Therm-RP 1200, 1400, 1600 Valve Housing

KRANZLE Therm-RP 1200, 1400, 1600 Valve Housing

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Valve housing 486010

2. O'Ring 40016

3. Inlet / outlet valve 42024

4. O'Ring 42025

5 .Valve plug 42026

6. Washer 8.4mm 50186

7. Hexagon socket screw 496253

10. Water inlet 1/2“ x 1“ 486035

13. Fabric sleeve 20mm 40023

14. Back ring 20mm 400251

15. O'Ring 40508

16. Intermediate ring 486034

17. Cu sealing ring 42033

18. Cuff 20mm 40512

19. Screw plug R 1/2" 42032

20. Pressure sleeve 20mm 486033

21. Water inlet part 1“ 486035

23. Pressure ring 20mm 40021

25. O'Ring 12256

26. Stainless steel seat Ø 8.2 13146

27. Snap ring 13147

29. Sealing ring 40019

30. Plug 3/8" 40018

31. Sealing plug 43043

32. Sealing plug 13158

33. Pump outlet part 402481

34. Stainless steel ball Ø10 12122

35. Check spring "K" 141201

36. Sealing plug 1/4" 13387

37. O'Ring 40016

38. Suction cup cleaning agent 13236

50. Repair kit valves 400621

52. Repair kit sleeves with brass parts 486040

53. Repair kit ball check valve 445661
