KRANZLE Therm-RP 1200, 1400, 1600 Motor

KRANZLE Therm-RP 1200, 1400, 1600 Motor

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Stator BG112 6.3 kW 400V / 50Hz 473700

2. A-bearing flange 473710

3. Rotor BG112 6.3 kW 400V / 50Hz 473720

4. Fan wheel BG112 6.3 kW 473711

5. Fan cover BG112 6.3 kW 473712

6. Terminal box 473713

7. Seal 473714

8. Terminal 473715

9. PG screw connection 473718

10. Bearing 6306 - 2Z 473717

11. Motor flange 473716

12. Key 485036

13. Ball bearing 6306 - 2Z 473717

14. Screw 49227

15. Shim 473719

16. Screw 43037

17. B-bearing flange 473730

21. Screw 44161

23. Eyebolt M10 473731

25. Unit bracket 44013

26. Vibration metal 44227

27. Washer Ø8.4 DIN 9021 41409

28. Hexagon socket screw 43059

29. Rubber buffer 434192

30. Hexagon nut 41410

35. Motor complete 243501
