KRANZLE Therm-RP 1200, 1400, 1600 Water Supply

KRANZLE Therm-RP 1200, 1400, 1600 Water Supply

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Water tank 440096

2. Float valve 440251

4. Clamping ring 44026

5. Connection piece R 3/8" IG 41423

7. Spring washer 44396

9. O'Ring 15017

10. Suction strainer 1" 444751

11. O'Ring 444780

12. Connection piece suction strainer 444781

13. Water inlet hose 44028

14. Intake hose 444770

16. HD hose water outlet 448402

17. Retaining washer 44841

18. Screw 410194

20. Water outlet part 13368

25. Screw plug 440091

26. Sealing ring 12387

30. Detergent valve complete 46616

31. Base part angle valve 46608

32. Valve needle 46601

33. Disc 43045

34. Parbaks 6mm 46606

35. O'Ring 12256

36. Guide part 46602

37. Handwheel 46609

38. Screw 44216

39. Nut 40185

40. Suction plug 13236

41. Hose clamp 44363

42. Plastic hose for detergent suction 44055

43. Plastic hose with filter 440561

45. Water tank complete with float valve 440097

consisting of: 1x Pos. 1; 1x Pos. 2; 1x Pos. 7;

1x Pos. 25; 1x Pos. 26;
