KRANZLE Therm-RP 1200, 1400, 1600 Hose Drum

KRANZLE Therm-RP 1200, 1400, 1600 Hose Drum

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Side shell hose guide 40302

2. Side shell water guide 40301

3. Drum lower section 40304

4. Drum upper section 40303

5. Hexagon socket screw 40313

6. Bearing block with brake 40327

7. Bearing block left 40305

8. Clamping piece 40307

9. Plastic screw 43018

10. Drive shaft 40328

11. Shaft water guide 40323

12. Elastic stop nut 40111

13. Crank cpl. 403200

16. Shaft retaining ring 22mm 40117

18. Washer 50189

19. Locking disc 40325

20. Sealing kit 134101

22. Screw 43021

23. Ermeto angle R1/4“ AG x 12L 44864

35. Holding bracket 44143

36. Rubber stopper 42613

37. Carriage bolt 41703

38. Elastic stop nut 41410

40. Hook 42612

42. O'Ring 13273

44. Connecting hose NW8 1m 44385

45. High pressure hose NW8 20m 443812

60. Hose reel complete

without hose, without retaining bracket 44392

61. Retaining bracket complete 441431
