KRANZLE Therm-RP 1200, 1400, 1600 Fire Box 1

KRANZLE Therm-RP 1200, 1400, 1600 Fire Box 1

Call For Pricing
Seen it Cheaper?

  • KRANZLE Therm-RP 1200, 1400, 1600 Fire Box 1

    Genuine Spare Parts

    See Diagram & Click the link for price & availability

    1. Bracket for ignition transformer with items 2 and 10 448211

    2. Support bracket 44395

    3. Ignition transformer 44074

    4. Screw 44113

    5. High-voltage ignition cable (2 pieces) 44114

    7. Ring nut 44115

    8. Spring ring 44222

    9. Stainless steel nut 141272

    10. Holding base ignition cable 44369

    11. Fuel line “nozzle holder” 120mm 44089

    12. Angle screw connection 44106

    13. Fuel line pump 441081

    14. Stainless steel screw 44177

    16. Self-tapping screw 44109

    17. Washer 50182

    18. Hexagon screw 44116

    19. Pressure measuring line 441021

    20. Blower nozzle 44068

    21. Blower housing 44353

    22. Fan wheel 44380

    23. Blower cover 44354

    24. Burner motor 200-240 V / 50/60 Hz 440726

    25. Plug-in coupling (from 10/2021) 448522

    27. Air slide 44355

    28. Screw 43426

    29. Screw 410194

    30. Screw 414141

    31. Toothed washer 43471

    32. Screw 44216

    33. Threaded 44090

    34. Washer 50152

    39. HD hose water outlet 44840

    40. Temperature sensor 44954 1

    41. Ermeto nut 12mm 40075

    42. T-screw-in fitting 44173

    43. Screw-in elbow fitting 3/8" x 12L 44092

    51. End ring 440861

    52. Threaded pin 44090

    53. Self-tapping screw 44564

    53.1 Self-tapping screw 44112

    54. Overtemperature sensor 44388

    55. Nut 44172

    56. Washer 50174

    57. Rotary knob for air slide 44358

    58. Locking washer 40315

    59. Counter bearing for air adjustment 44356

    60. Shaft for air adjustment 44382

    61. Gear wheel drive air slide 44357

    62. Screw 44525

    82. Blower unit 44390
