KRANZLE Therm-RP 1200, 1400, 1600 Unloader
Genuine Spare Parts
See Diagram & Click the link for price & availability
5. O'Ring 13150
5.1 O'Ring 42167
8. O'Ring 12256
9. Stainless steel seat 14118
10. Retaining ring 13147
11. Stainless steel ball 8.5mm 12245
12. Stainless steel spring 14119
13. Screw plug 14113
14. Control piston 486031
15. Parbaks 16mm 13159
16. Parbaks 8mm 14123
17. Spring pin 14148
18. Piston guide 14130
19. Nut 14144
20. Valve spring black 14125
21. Spring pressure disc 14126
22. Needle bearing 14146
23. Handwheel 141472
26. Parbaks 7mm 15013
27. Valve plug AQ with pressure part for electric switch 420263
28. Washer 50152
29. Countersunk screw 44091
49. O'Ring 12136
50. O'Ring 15014
51. Guide part control tappet 490580
52. O'Ring 15017
53. O'Ring 43445
54. Parbaks 4mm 121362
55. Support disc dm515015
55.1 Support disc dm4 150151
57. Control tappet long 150102
58. Parbaks 15013
59. Plug M10x1 (drilled through) 133851
60. Housing electric switch (black) 15204
60.1 Electrical switch housing (red) 15205
61. Rubber sleeve 15202
63. Union nut PG 11 15203
64. Cable 2 x 1.0 mm² 0.70 m black 44367
64.1 Cable 2 x 1.0 mm² 0.70 m grey 44368
65. Self-tapping screw 15024
66. Electrical switch cover (black) 15201
66.1 Electrical switch cover (red) 152011
67. O'Ring 15023
68. Micro switch 44262
69. Cylinder head screw 15025
70. Hexagon nut 12138
72. Compression spring 40520
73. Base part electric switch 15009
74. Control piston 15010
75. O'Ring 40016
80. Control piston complete with handwheel 486032
81. Repair kit pressure switch mechanism 150093
82. Pressure switch (red) without mechanism 443891
83. Valve housing complete 486050
84. Repair kit pressure switch mechanism 150114
85. Pressure switch (black) without mechanism 44389
86. Pressure switch (red) with mechanism (item 81 + 82) 443892
-
