KRANZLE Therm-RP 1200, 1400, 1600 Fire Box 2

KRANZLE Therm-RP 1200, 1400, 1600 Fire Box 2

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Outer casing with base plate 44379

2. Nozzle holder cover 44079

3. Inner casing with base plate 44378

5. Inner cover with flame tube 44377

6. Outer cover 44066

7. Fuel nozzle 60° B 1.50 gph for RP 1000 44077

7.1 Fuel nozzle 60° B 1.65 gph

for RP 1200/RP 1400 / RP 1600 440773

8. Block electrode 44080

9. Nozzle holder Ø 25mm, 6 slots 440764

10. Nozzle holder 44078

11. Stainless steel screw 44177

12. Clamping plate for electrode 440761

13. Cylinder head screw with ISK 440762

15. Intermediate sleeve 44376

19. Stainless steel nut 141272

20. Spring washer 44222

21. Optical flame sensor 442561

22 .Screw 46002

25. Heating coil 44374

27. Insulation plate 44360

Inner chamber cpl. 44399

Item 3, 5, 15, 19, 20, 25, 27
