KRANZLE Therm-RP 1200, 1400, 1600 Switch Box
Genuine Spare Parts
See Diagram & Click the link for price & availability
1. Electrical box 448071
2. Cover for electrical box therm 470141
3. Front panel pressure gauge 443751
6. Bracket for switch 44810
8. Bracket for thermostat 47012
9. Seal for thermostat 47013
13. Seal for cover overtemp 441821
14. Control panel for control board 44257
15. Cover for overtemperature release 44182
16. Control board overtemperature release 44370
19. Earth terminal 44839
21. Washer 4.3 DIN9021 43472
22. Control board 400 V / 50/60 Hz 44359
23. Contactor 400 V / 50/60 Hz 23 A 444004
24. Screw 4.0 x 25 with tested. Disc 43425
25. Overcurrent release 3-pole 11.3-16A 42641
26. Cable trumpet with strain relief 44819
28. Screw 3.5 x 14 44525
29. Mains connection cable three-phase
8.0m, 4x 2.5 mm², H07RNF 42812
30. PG16 screw connection 1 feedthrough 414191
31. PG16 screw connection 2 feedthroughs 44132
32. PG16 screw connection 3 feedthroughs 44133
34. Fuel pressure gauge 443620
35. Connector R1/4“ IG-DN-6 angle 44409
37. Fine fuse 1.25 A slow-blow 44676
38. Fine fuse 2.0 A slow-blow 448891
39. Fine fuse 630 mA slow-blow 442002
40. Retaining bridge 44352
42. Fine fuse 32 mA slow-blow 442001
45. Grommet for capillary tube 44823
47. Seal for electrical box 44838
48. Clamp for pressure gauge 44049
49. Connection sleeve for pressure gauge 44136
-
Download Documents
Downloads for this product are currently unavailable, please get in contact if you require any documentation.
