KRANZLE Therm CA 11/130 Hose Drum

KRANZLE Therm CA 11/130 Hose Drum

Seen it Cheaper?

KRANZLE Therm CA 11/130 Hose Drum

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Side shell hose guide 40302

2. Side shell water supply 40301

3. Drum lower part 40304

4. Drum upper part 40303

5. Allen screw 40313

6. Bearing block with brake 40327

7. Bearing block left 40305

8. Clamping piece 40307

9. Screw 43018

10. Drive shaft 40328

11. Shaft water supply 40311

12. Elastic stop nut 40111

13. Foldable hand crank 403200 (Discontinued)

13. Foldable hand crank 403201

15. Disc 40181

16. Shaft retaining ring 22mm 40117

17. Shaft retaining ring 16mm 40182

19. Locking disk 40325

20. Parbaks 16mm 13159

22. Screw 43021

23. Swivel joint 40167

25. Spacer ring 40316

27. O'Ring 40585

28. Connection piece 40308

33. O'Ring 13386

34. Plugs 13385

35. Retaining bracket 44143

36. Rubber stoppers 42613

37. Carriage bolt 41408

38. Elastic stop nut 41410

40. Union nut 132762

42. O'Ring 132731

44. Connecting hose NW8 1m 44160

45. High pressure hose NW8 15m 44879

Hose drum complete without hose, without bracket 41259

51 Retaining bracket complete 441431
Download Documents

Downloads for this product are currently unavailable, please get in contact if you require any documentation.
