KRANZLE Therm CA 11/130 Assembly

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Chassis 44800

2. Axle 44820

3. Wheel d250 460102

4. Spring pin 401151

5. Hub cap 46011

6. Screw 43037

7. Black water tank 448051

8. Screw 44831

9. Tank cap with item 10 44005

10. O-ring 44020

11. Fuel tank black 448061

12. Rear hood 44812

13. Screw 40536

14. Front hood 44813

15. Chimney cover 44825

16. Push bars 44834

17. Quiver pot 465031

18. Lance holder 42610

19. Lance stand 465021

20. Screw 401711

21. Sheet metal screw 44161

22. Screw 46024

23. Screw 40178

24. Supply air cover 44801

25. Drain plug 440041

26. Gasket for drain plug 410471

27. Washer 41409

28. Screw 44832

29. Washer hood fastening 44849

30. Washer 41409

31. Screw 44826

32. Disc 46533

36.1 Motor pump for therm CA 11/130 44960

36.2 Motor pump for therm CA 12/150 44961

37. High pressure hose NW 8 10 m 44878

37.1 High pressure hose NW 8 15 m 44879

38. O-ring 132731

39. Starlet 3 12500

40. Lance 1000mm with flat jet nozzle 12420-D25045

41. Engine mount 44950

42. Rubber damper 44891

43. Lens screw 13190

44. Lance holder left for Kränzle therm C 44971

45. Lance holder right for Kränzle therm 44970
