KRANZLE Therm 895-1, Therm 1165-1 Motor

KRANZLE Therm 895-1, Therm 1165-1 Motor

Seen it Cheaper?

KRANZLE Therm 895-1, Therm 1165-1 Motor

Genuine Spare Parts

See Diagram & Click the link for price & availability

2. A-bearing flange 405270

4. Fan wheel BG112 incl. clamp 473711

5. Fan cover BG112 473712

6. Terminal box 473713

7. Gasket 473714

8. Terminal 473715

9. PG fitting M25x1.5 473718

10. Bearing 31306 J 2 40103

11. Shaft seal 35 x 47 x 7 40080

12. Key 8 x 7 x 28 40459

13. Ball bearing 6306 - 2Z 473717

14. Hex socket screw M6 x 80 43037

15. Shim 473719

16. Hex socket screw M6 x 30 43037

17. B-bearing flange 473730

21. Screw 3.5 x 16 44161

23. Eye bolt M10 473731

25. Aggregate bracket 44013

26. Vibration damper 30x30 44227

27. Washer Ø8.4 DIN 9021 41409

28. Hex socket screw M8x40 43059

29. Rubber buffer 15x20 434192

30. Hex nut M8 41410

35. Motor complete BG112 400V 3~50Hz 5.5kW 244001
