KRANZLE Small Quadro 11/140 TST Valve Housing
Genuine Spare Parts
See Diagram & Click the link for price & availability
1. Valve housing 421603
2.1 Valve plug with R1/4“ IT 42102
3. Sealing plugs 43043
4. Valves (green) for APG pump 417151
7. Sealing plug R1/4" with collar 42103
11. Aluminum sealing ring 13275
12. Output part pump 46039
14. Ermeto angle 440921
16. Stainless steel ball Ø10 12122
17. Check spring 141201
19. Stainless steel seat Ø 7 14118
19.1 Washer 6 mm 43045
20. Basic part angle valve 46600
21. Valve needle 46601
22. Parbaks 6 mm 46606
23. Leadership part 46602
24. Handwheel 46603
25. Screw 46604
28. Cuff 410132
29. Backing ring 410142
32. Intermediate ring 18 mm 410152
44. Allen screw 410172
Repair set valves for APG pump 417481
consisting of 6x item 4 each; 6x item 5; 6x item 6
Repair set for cuffs 18 mm 410491
consisting of 3x item 27 each; 3x item 28;
3x item 28.1; 6x item 29; 3x item 30
consisting of 1x item 18-26 each
-
Download Documents
Downloads for this product are currently unavailable, please get in contact if you require any documentation.
