KRANZLE B 170 T Valve Housing

KRANZLE B 170 T Valve Housing

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Valve housing APG 421604

2. Valve plugs 41714

2.1 Valve plug 42102

3. Sealing plugs 43043

4. Valves (green) for APG pump 417151

5. O-ring 13150

6. O-ring 41716

7. Sealing plugs R 1/4" with collar 42103

8. Output part R3/8" IT 402481

9. Sealing plugs 13158

10. O-ring 40016

11. Aluminum sealing ring 13275

12. Plugs 1/4" male with ISK 13387

13. O-ring 12256

14. Stainless steel seat Ø 7 14118

15. Snap ring 12258

16. Stainless steel balls Ø10 12122

17. Check spring “K” 141201

27. Pressure ring 41018

28. Cuff 410132

28.1 Fabric sleeve 410131

29. Backing ring 41014

30. O-ring 40026

31. Leakage ring 41066

32. Intermediate ring 410152

33. Sealing plug 14113

34. Copper ring 40019

40. Screw-in angle 40256

41. ST30 nipple 133652

42. Usit ring 42104

43. Allen screw 410363

44. Allen screw 410172

46. Suction connection 41016

47. Water filter 410461

49. Plug-in coupling 410474

Repair set valves for APG pump

consisting of 6x item 4 each; 6x item 5; 6x item 6 417481

Repair set for cuffs 18 mm

consisting of 3x item 27 each; 3x item 28;

3x item 28.1; 6x item 29; 6x item 30 410491

Valve housing complete with handwheel 40249
