KRANZLE B 230, B 240, B 270 T Valve Housing
Genuine Spare Parts
See Diagram & Click the link for price & availability
1. Valve housing AQ with integrated. UL 405212
2. O-ring 40016
3. Inlet / outlet valve 42024
4. O-ring 42025
5. Valve plug 42026
5.1 Valve plug with R 1/4" IT 420262
6. Circlip 40032
7. Allen screw 40504
13. Fabric sleeve 40023
14. Backing ring 20 mm 400251
15. O-ring 40508
16. Leakage ring 40509
17. Cu sealing ring 42033
18. Rubber sleeve 40512
19. Closing screw R 1/2" 42032
20. Spacer ring with support 40507
23. Pressure ring 20 mm 40021
24. Intermediate ring 20 mm 40516
26. Stainless steel seat Ø 7 14118
29. Sealing ring (copper) 40019
30. Plugs 3/8" with 1/8" IT 40242
31. Sealing plug 43043
34. Stainless steel ball Ø10 12122
38. Output piece R3/8“ IT 402481
40. Screw-in angle R3/8" AG x R3/8" IT 40256
41. ST30 nipple R3/8" AG x M22 x 1.5 133652
45. Angle screw connection R 1/8" 441101
49. Spacer tube 48 mm on both sides R3/8" AG 41628
50. Angle R3/8" IT / IT 44138
51. Suction connection R 3/8" AG x R3/4" 41016
consisting of: 3x item 13; 6x item 14; 3x item 15; 3x pos.
16; 3x item 18; 3x item 20; 3x item 23
Repair kit for cuffs without 40517
Brass parts consisting of: 3x item 13; 6x item 14; 3x
Item 15; 3x item 18; 3x item 23
-
