KRANZLE B 230, B 240, B 270 T Unloader
Genuine Spare Parts
See Diagram & Click the link for price & availability
5. O-ring 13150
5.1 O-ring 42167
11. Stainless steel ball 12245
12. Stainless steel spring 14119
14. Control piston 14134
18. Piston guide special 42105
19. Lock nut 14144
20. Valve spring black (B20/200) 14125
20.1 Valve spring red (B16/220, B16/250) 141251
21. Spring pressure washer 14126
22. Needle bearings 14146
23. Handwheel 14147
25. Elastic stop nut 14152
26. Pressure gauges 0-400 bar 150394
27. Aluminum sealing ring 13275
53. O-ring 43445
57. Blind closure with seals 44551
58. Parbaks 7 mm 15013
70. Control pistons complete. with handwheel (B230T) 43444
70.1 Control piston cpl. with handwheel (B240T, B270T) 434441
-
Download Documents
Downloads for this product are currently unavailable, please get in contact if you require any documentation.
