KRANZLE B 230, B 240, B 270 T Transmission

KRANZLE B 230, B 240, B 270 T Transmission

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Oil housing 40501

2. Cu sealing ring 40052

3. Oil drain plugs 42019

4. Allen screw 40053

5. Lock washer 40054

6. Flat gasket 40035

7. Oil seal 400441

8. Wave washer 40043

9. Axial roller cage 40040

10. AS washer 40041

11. Swashplate 10.2° for B230 T 40055-10.2

Swashplate 8.0° for B240 T 40055-8.0

Swashplate 8.0° for B270 T 40055-8.0

12. Plunger spring 40506

13. Spring pressure washer 40510

14. Plungers 20 mm (long) 40505

15. Snap ring 40048

16. O-ring 43445

18. Flat gasket 410193

19. Oil housing cover 40518

20. Allen screw 410194

21. Oil dipstick 42520

22. Support washer 40513

24. Housing washer 40039

25. Allen screw 410363

26. Copper sealing ring 41500

27. Sealing ring 40224

28. Flange for B 16/220 40223

30. Engine Honda GX 340 LX2 24026

30.1 Engine Honda GX 390 LX2 240261

52. Roll pin 141481

53. Step wedge 40222

30. Engine Honda GX 340 for B 16/220 24026

30.1 Engine Honda GX 390 for 20/200 240261

52. Roll pin 141481

53. Step wedge 40222
