KRANZLE B 13/150 Profi Jet Valve Housing

KRANZLE B 13/150 Profi Jet Valve Housing

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Valve housing APG 421603

for 18 mm plunger diameter

2. Valve plugs 41714

2.1 Valve plug with R1/4“ IT 42102

3. Sealing plugs 43043

4. Valves (green) for APG pump 417151

5. O-ring 13150

6. O-ring 41716

7. Sealing plug R 1/4" with collar 42103

8. Output part 405221

9. Sealing plugs 13158

10. O-ring 40016

11. Aluminum sealing ring 13275

12. Plugs 1/4" male with ISK 13387

13. O-ring 12256

14. Stainless steel seat Ø 7 14118

15. Snap ring 13147

16. Stainless steel ball Ø10 12122

17. Check spring “K” 141201

27. Pressure ring 41018

28. Cuff 410132

28.1 Fabric sleeve 410131

29. Backing ring 41014

30. O-ring 40026

31. Leakage ring 41066

32. Intermediate ring 410152

33. Sealing plug 14113

34. Copper ring 40019

42. Usit ring 42104

43. Allen screw 410363

44. Allen screw 410172

46. Suction connection 41016

47. Water filter 410461

49. Plug-in coupling 410474

Repair kit Valves for APG Pump 417481

composition of 6x No. 4; 6x No. 5; 6x No. 6

Repair kit sleeves 18 mm 410492

consisting of 3x No. 27; 3x No. 28;

3x No. 28.1; 6x No. 29; 6x No. 30

Valve housing compl. 43442

with integr. ULH
