KRANZLE LX-RP 1200, 1400, 1600 TST Gun with Lance

KRANZLE LX-RP 1200, 1400, 1600 TST Gun with Lance

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Valve body with handle 12294

2. Protective sleeve 12295

3. Cover protection 12296

4. Operating levers gray 122983

5. Safety lever 12149

6. End screw 12247

7. Stoppers 12287

8. Thread guide sleeve Ø3 R 1/4“ AG 122501

9. Pilot bolt Ø3 122841

10. Pin 12148

11. Bearing needle 12253

12. Stainless steel spring 12246

13. Stainless steel ball Ø10 12122

14. Stainless steel seat Ø8.2 13146

15. O-ring 12256

16. O-ring 121361

17. Screw 41079

19. Plug nipples hardened stainless steel R1/4“ IT 13470

20. Pipe 965 long, both sides 1/4" AG 13519

21. Handle shells lance 12406

22. Screw 44525

23. Nozzle protection 26002

24. O-ring 121291

25. Flat jet nozzle D40065 (LX-RP 1200) D40065

25.1 Flat jet nozzle D4008 (LX-RP 1400) D4008

25.2 Flat jet nozzle D4011 (LX-RP 1600) D4011

26. Sliding shoe Ø3 122891

27. Circlip 13147

28. Plug-in coupling R 3/8“ AG 13453

29. O-ring 13460

39. Starlet II E:ST30 Nip. M22x1.5 AG A: plug-in coupling 123272

40. Starlet II E:M22x1.5 AG A:3/8“IG 12329

Rep. set “Starlet II” 12299

consisting of 1x position each: 8, 9, 13-16, 24-26
