KRANZLE LX-RP 1200, 1400, 1600 TST Valve Housing

KRANZLE LX-RP 1200, 1400, 1600 TST Valve housing

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Valve housing 486010

2. O-ring 40016

3. Inlet/exhaust valve 42024

4. O-ring 42025

5. Valve plug 42026

6. Washer 8.4mm 50186

7. Allen screw 496253

8. Valve plugs with R1/4“ IT 420262

9. Aluminum sealing ring 132751

10. Quick coupling 3/4“ male thread 487031

13. Fabric sleeve 20 mm 40023

14. Backing ring 20 mm 400251

15. O-ring 405081

16. Intermediate ring 486034

17. Cu sealing ring 42033

18. Sleeve 20 mm 40512

19. Screw plug R 1/2" 42032

20. Pressure sleeve 20 mm 486033

21. Water inlet part 1" 486035

23. Pressure ring 20 mm 40021

25. O-ring 12256

26. Stainless steel seat Ø 8.2 13146

27. Snap ring 13147

29. Sealing ring 40019

30. Plugs 3/8" 40018

31. Sealing plug 13385

32. Sealing plugs 13158

33. Output part pump 402481

34. Stainless steel ball Ø10 12122

35. Recoil spring "K" 141201

36. Sealing plugs 1/4" 13387

37. O-ring 40016

50. Repair set valves 400621

52. Repair set of cuffs with brass parts 486040

53. Repair kit ball check valve 40491
