KRANZLE LX-RP 1200, 1400, 1600 TST Hose Drum

KRANZLE LX-RP 1200, 1400, 1600 TST Hose Drum

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Side tray 403190

3. Drum lower part 40304

4. Drum upper part 40303

5. Allen screw 40313

6. Bearing block with brake 403271

7. Bearing block left 40305

8. Clamping piece 40307

9. Screw 43018

10. Drive shaft 40328

11. Shaft water supply 40323

12. Elastic stop nut 40111

13. Crank cpl. 403200

16. Shaft retaining ring 22 mm 40117

18. Washer 50189

19. Locking washer 40325

20. Sealing set 134101

22. Screw 43021

23. Ermeto angle R1/4“ AG 44864

40. Hooks 42612

42. O-ring 13273

44. Connecting hose 487300

45. High pressure hose NW 8 20 m 443812

60. Hose reel complete.

without hose, without bracket
