KRANZLE LX-RP 1200, 1400, 1600 TST Motor

KRANZLE LX-RP 1200, 1400, 1600 TST Motor

Call For Pricing
Seen it Cheaper?

  • KRANZLE LX-RP 1200, 1400, 1600 TST Motor

    Genuine Spare Parts

    See Diagram & Click the link for price & availability

    1. Stator BG112 6.3 kW 400V / 50Hz 473700

    2. A-bearing flange 473710

    3. Rotor BG112 6.3 kW 400V / 50Hz 473720

    4. Fan wheel BG112 6.3 kW 473711

    5. Fan cover BG112 6.3 kW 473712

    6. Adapter plate 473740

    7. Seal 473714

    8. Terminal 473715

    9. PG screw connection 473750

    10. Bearings 473717

    11. Motor flange 473716

    12. Feather key 485028

    13. Ball bearings 473717

    14. Screw 49227

    15. Compensating washer 473719

    16. Screw 43037

    17. B-bearing flange 473730

    18. Screw 43426

    21. Screw 44161

    23. Eyebolt M10 473731

    24. Screw 43417

    25. Allen screw 42542

    26. Switches with push buttons 42644

    27. Screw 414141

    28. Screw 43415

    29. Luster terminal 5-pin. 433261

    30. Contactor 100-C23KN10 3x400V 50/60 Hz 444004

    31. Switch box lower part 460122

    32. Switch box cover 460132

    33. Control board switch-off delay. 42563

    34. Clamp frame with switch seal 43453

    36. Screw 44161

    37. PG 16 screw connection 414191

    38. Gasket for switch box cover 460131

    39. Lock nut for PG9 screw connection 410871

    40. Lock nut for PG16 screw connection 44119

    41. PG 9 - screw connection 42541

    42. Overcurrent release 3-pole 9 – 16 A 42641

    43. Pan head screw 414142

    44. Cover plate for switch box 487150

    Power connection cable CE-KON 4x2.5mm² 44190

    51. Engine cpl. without power cable 243501

    52. Switch box LX-RP 1200 - LX-RP 1600 complete.

    without power cable 487170
