KRANZLE Large Quadro 899/1000/1200 TST Valve Housing
Genuine Spare Parts
See Diagram & Click the link for price & availability
1. valve housing AQ with integrated. UL and pressure switches
(TST) 405035
3. Inlet/exhaust valve 42024
4. O-ring 42025
5. Valve plug 42026
5.1 Valve plug with R 1/4“ IT 420262
6. Circlip 40032
7. Allen screw 40504
8. Hose nipples 42634
9 Hose clamp 440545
10. Chemical suction hose with filter 42621
13. Fabric cuff 40023
14. Backing ring 400251
15. O-ring 40508
16. Leakage ring 40509
17. Cu sealing ring 42033
18. Rubber sleeve 40512
19. Closing screw 42032
20. Spacer ring with support 40507
21. Aluminum sealing ring for quadro TS 132751
22. Sealing plugs for quadro TS 13387
23. Pressure ring 20 mm 40021
24. Intermediate ring 20 mm 40516
26. Stainless steel seat 14118
28. Output part pump 44215
29 Sealing ring 17 x 22 x 1.5 (copper) 40019
31. Sealing plug 43043
32. Sealing plugs 13158
33. Output part for quadro TST 40522
33.1 Output part M22x1.5 for quadro TS 405221
34. Stainless steel ball Ø10 12122
37. O-ring 40016
38. Usit Ring 12387
60. repair set for cuffs with brass parts 400651
consisting of: 3x item 13; 6x item 14; 3x item 15;
3x item 16; 3x item 18; 3x item 20; 3x item 23
61. Repair set for cuffs without brass parts 40517
consisting of: 3x item 13; 6x item 14; 3x item 15; 3x item 18; 3x item 23
-
