KRANZLE Large Quadro 899 TST, 1000/1200 TS/TST Unloader

KRANZLE Large Quadro 899 TST, 1000/1200 TS/TST Unloader

Call For Pricing
Seen it Cheaper?

  • KRANZLE Large Quadro 899 TST, 1000/1200 TS/TST Unloader

    Genuine Spare Parts

    See Diagram & Click the link for price & availability

    5. O-ring 13150

    5.1 O-ring 42167

    8. O-ring 12256

    9. Stainless steel seat 14118

    10. Circlip 13147

    11. Stainless steel ball 12245

    12. Stainless steel spring 14119

    13. Screw plug 14113

    14. Control piston 14134

    15. Parbaks 16 mm 13159

    16. Parbaks 8 mm 14123

    17. Chip pin 14148

    18. Piston guide special 42105

    19. Lock nut 14144

    20. Valve spring red (quadro 800 - quadro 1000) 141251

    21. Spring pressure washer 14126

    22. Needle bearings 14146

    23. Handwheel 14147

    25. Elastic stop nut 14152

    26. Pressure gauge 0-400 bar 150394

    27. Aluminum sealing ring 132751

    40. Hexagonal nut 12138

    42. Compression spring 40520

    50. O-ring 12136

    51. Guide part control tappet 490580

    52. O-ring 15017

    53. O-ring 43445

    54. Parbaks 121362

    55. Support disk 150151

    57. Control plungers 150102

    58. Parbaks 10 mm 15013

    59. Plug M 10 x 1 (drilled through) 133851

    60. Housing electrical switch 15204

    61. Rubber sleeve PG 15202

    63. Union nut PG 15203

    64. PVC cable 42505

    65. Screw 15024

    66. Cover electrical switch 15201

    67. O-ring 15023

    68. Micro switches 44262

    69. Cylinder screw 15025

    70. Control pistons complete. (quadro 800 - quadro 1000) 434441

    70.1 Control piston cpl. (quadro 1200) 43444

    71. Rep. set of pressure switch mechanism 150093

    72. Pressure switches complete. 426510

    73. Valve housing complete. quadro 800 TST - quadro 1000 TST 405038

    73.1 Valve housing complete. quadro 1000 TS 405039

    73.2 Valve housing complete. quadro 1000 TS 405039

    73.3 Valve housing complete. quadro 1200 TS 426381

    73.4 Valve housing complete. quadro 1200 TST 405036

  • Download Documents

    Downloads for this product are currently unavailable, please get in contact if you require any documentation.
