KRANZLE Large Quadro 899 TST, 1000/1200 TS/TST Transmission

KRANZLE Large Quadro 899 TST, 1000/1200 TS/TST Transmission

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Oil housing 40501

4. Allen screw 410363

6. Flat gasket 40035

7. Oil seal 400441

9. Axial cylindrical roller bearings AQ pump 40524

11.1 Swashplate AQ 9.85° 40523-9.85

at quadro 800 TST

11.2 Swashplate AQ 10.8° 40523-10.8

at quadro 1000 TST + 1000 TS

11.3 Swashplate AQ 12.75° 40523-12.75

for quadro 1200 TST + 1200 TS

12. Plunger spring 40506

13. Spring pressure washer 40510

14. Plungers 20 mm (long) 40505

15. Snap ring 40048

16. O-ring 43445

18. Flat gasket 410193

19. Flat cover for oil housing 410231

20. Allen screw 410194

21. Oil dipstick 40463

22. Support washer for plunger spring 40513

23. O-ring 42167

24. Oil drain plug 42019

Oil housing AQ cpl. without swashplate 40514

Items 1, 4-7, 12-17, 22
