KRANZLE Large Quadro 899 TST, 1000/1200 TS/TST Motor

KRANZLE Large Quadro 899 TST, 1000/1200 TS/TST Motor

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Stator 112 5.5 kW 400 V / 50 Hz 40540

2. A-bearing flange 40530

3. Rotor 112 (400 V / 50 Hz) 40531 5

4. Fan wheel for BG 405321

5. Fan cover 40533

6. V-Seal 40545

7. Flat gasket 43030

10. Tapered roller bearings 40103

11. Oil seal 40080

12. Feather key 40459

13. Ball bearings 40538

14. Allen screw 43037

19. Screw 41489

21. Screw 41489

22. Ground screw complete. 43038

23. Switches with push button operation 42644

24. Screw 43417

25. Buck for switch 42608

26. Screw 414141

28 Screw 43415

29. 5-pole luster terminal. 433261

30. Contactor 460051

31. Switch box lower part 42606

32. Switch box cover 42607

33. Control board switch-off delay. 400V / 50Hz 42563

34. Clamp frame with switch seal 43453

36. Screw 44161

37. PG 16 screw connection 414191

38. Gasket for switch box cover 42525

39. Lock nut for PG9 screw connection 410871

40. Lock nut for PG16 screw connection 44119

41. PG 9 - screw connection 42541

42. Overcurrent release 3-pole 11.3-16 A 42641

50. Engine complete. without switch 24060

51. Switch box complete. 42631
