KRANZLE K 2160 & 2175 TS/TST Valve Housing
Genuine Spare Parts
See Diagram & Click the link for price & availability
1. Valve housing (TS) 421605
1.1 Valve housing (TST) 42160
2. Valve plugs 41714
2.1 Valve plugs with R1/4“ 42102
3. Sealing plugs 43043
4. Valves (green) for APG pump 417151
5. O-ring 13150
7. Sealing plugs R1/4 “ 42103
8. Exit section (TST) 40522
8.1 Exit section (TS) 405222
9. Sealing plugs 13158
11. Aluminum sealing ring 132751
12. Screw connection 41042
14. Stainless steel seat 14118
16. Stainless steel ball Ø10 12122
17. Check spring 141201
27. Pressure ring 41018
28. Sleeve 410132
28.1 Fabric sleeve 410131
29. Baking ring 410142
30. O-ring 40026
31. Leakage ring 18 mm 41066
32. Intermediate ring 18 mm 410152
38. O-ring 13386
39. Suction spigot hose connection 13236
40. Stainless steel ball 5.5 mm 13238
41. Stainless steel spring 13239
43. Hexagon socket screw 410363
44. Hexagon socket screw 41017
48. Rubber sealing ring 410471
49. Plug-in coupling 410474
50. O-ring 410473
62. Repair kit for valves for APG pump 417481
63. Repair kit for sleeves 18 mm 410491
64. Repair kit check valve 44566
-
