KRANZLE K 2160 & 2175 TS/TST Transmission

KRANZLE K 2160 & 2175 TS/TST Transmission

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Housing plate for 18 mm plunger 410202

2 Oil seal 41031

3. O-ring 410211

4. Plunger spring 41033

5. Spring pressure washer 41034

6. Plunger 18 mm 410321

7. Snap ring 18 mm 41035

8. Swashplate 90 ° (K2160 TS/ TST) 41028-11.75

8.1 Swashplate 13.0 ° (K2175 TS/ EST) 41028-13.0

10. Axial groove ball bearing 43486

12. Hexagon socket screw 410363

14. O-ring 43445

15. Gasket for cover 46531

16. Cover for oil housing 46532

17. Screw 410194

18. Oil plug screw with dipstick 48017

20. Oil drain plug with magnet 48020
