KRANZLE K 2000 Series Motor

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Oil housing for AP with cover and seal 465302

3. Rotor with motor shaft 43316

4. Key 414831

5. Motor bearing B side 43317

6. Motor bearing shoulder bearing 41027

8. Oil seal 41024

9. Fan wheel 411181

10. Fan cover 43320

11. Flat gasket 43030

12. Allen screw 43037

15. Screw 41489

16. Grounding screw complete 43038

20. Switch box 48001

21. Cover for switch box 445121

22. Clamp frame with switch seal 43453

23. Screw 41088

24. Seal for cover 44522

25. Screw 43018

27. Cable gland 40539

28. Lock nut 44253

29. Cable gland 41419

30. Lock nut 44521

31. Luster terminal 3-pole 43326

32. Screw 43415

For K 2160 TS/ TST and K 2195 TS/ TST

2.1 Motor housing 43826

14.1 Cable with plug 41092

18. Capacitor 70 µF 1 43322

26.1 Switch 411117

40.1 Switch box cpl. (items 18 - 32) 48052

41.1 Motor alternating current cpl. without switch (items. 1 - 16) 48054

For K 2175 TS/ TST

2.2 Motor housing with stator three-phase current 43827

14.2 Cable with plug 410921

26.2 Switch 41751

33. Contactor 48016

34 Screw 41078

40.2 Switch box three-phase complete (items 20 - 34) 48053

41.2 Motor three-phase cpl. without switch (items 1 - 16) 48055
