KRANZLE E-Therm 500 M 24kW, 603 M 36kW, 873 M 48kW Assembly
Genuine Spare Parts
See Diagram & Click the link for price & availability
1. Cockpit e-therm 443512
2. Fuel tank 442680
3. Water box (not for 18kW and 24kW) 44009
4. Cover 44241
5. Lance holder 44008
13. Fuel filler cap with O-ring, unmarked 442701
14. Chassis 440011
15. Front bar 44002
17. Railing 440161
20. O-ring 53.34 x 5.33 442710
21. Hex socket screw M8 x 12 40122
22. Hex socket screw M8 x 40 44033
27. Carriage bolt M 8 x 35 41408
31. Gasket for drain plug 410471
32. Mounting plate for control box 447703
33. Plastic screw 6 x 30 434231
34. Fuel strainer 442690
36. Screw DIN912-A2 M8 x 20 41480
37. High-pressure hose NW 8 10m 41081
37.1 High-pressure hose NW 8 20m 443812
38. O-ring 9.3 x 2.4 Viton 132731
40. Lance with flat jet nozzle 2503 (18kW, 24kW) 12420-D2503
40.1 Lance with flat jet nozzle 25035 (36kW) 12420-D25035
40.2 Lance with flat jet nozzle 2505 (48kW) 12420-D2505
41. Lance holder left for Kränzle therm 44412
42. Lance holder right for Kränzle therm 44411
43.1 Mains connection cable 4 x 6mm² with plug 32A (18kW) 446501
43.2 Mains connection cable 4 x 10 mm² with plug 63 A (24 kW) 446504
43.3 Mains connection cable 4 x 16 mm² with plug 63 A (36 kW) 446502
43.4 Mains connection cable 4 x 25 mm² with plug 125 A (48 kW) 446503
44. Chimney grille 447726
45. Locking piece 44773
46. Countersunk screw DIN 912 M4 x 35 402361
47. Sheet metal screw DIN 7981 6.3 x 13 44109
48. Washer 6.4 DIN 9021 50174
49. Pan head screw M5 x 20 13190
50. Hex socket screw M8 x 12 with M4 internal thread 440191
Fan 230V 446264
-
