KRANZLE E-Therm 500 M 24kW Motor

Genuine Spare Parts

See Diagram & Click the link for price & availability

1. Oil housing for AP with cover and gasket 465302

2. Motor housing with stator AC 43826

3. Rotor with motor shaft 43316

4. Key 6 x 6 x 20 414831

5. Motor bearing B-side 6205 - 2Z 43317

6. Motor bearing shoulder bearing 7304 41027

8. Oil seal 25 x 35 x 7 41024

9. Fan wheel BG 90 411181

10. Fan cover BG 90 43320

11. Flat gasket 43030

12. Hex socket screw M 6 x 30 43037

15. Screw M 4 x 12 41489

16. Grounding screw complete 43038

20. Terminal box 405341

21. Cover for switch box 445121

22. Terminal block, 3-pole 43326

23. Sheet metal screw 3.5 x 19 44162

24. Pan head screw M4 x 16 DIN 7985 42542

25. Aggregate bracket 44013

26. Vibration damper 30x30 44227

27. Washer Ø8.4 DIN 9021 41409

28. Hex socket screw M8x40 43059

29. Rubber buffer 15x15 43419

30. Elastic-Stop nut M8 41410

31. Adapter plate 41123

32. Screw M8 x 12 40122

33. Spacer for rubber buffer 444740
