KRANZLE 1152 TS / TST Unloader

KRANZLE 1152 TS / TST Unloader

Genuine Spare Parts

See Diagram & Click the link for price & availability

7. O'Ring 150051

8. O'Ring 12256

9. Stainless Steel Seat 14118

10. Circlip 13147

11. Start Up Relief Valve 49041

12. Spring 49042

13. Locking Screw 49043

14. Control Piston 44532

15. Parbanks For Pistons 14mm 141231

16. Parbanks For Spindle 6mm 141232

18. Piston Guide 141301

19. Nut 141271

20. Spring 43046

21. Spring 43047

22. Ball Bearings 43048

23. Red Knob Only 43049

24. Nut 43010

25. Cap 43050

26. Pressure Gauge 15039

28. Sealing Ring 132751

49. Spring 40520

50. O'Ring 12136

51. Guide Part Control Tappet 490580

52. O'Ring 15017

53. O'Ring 43445

54. Parbaks 121362

55. Support Disc 150151

57. Control Plunger Long 150102

58. Parbaks 15013

59. Plug 133851

60. Electric Switch Housing 15204

61. Rubber Sleeve 15202

62. Hexagon Nut 12138

63. Union Nut 15203

64. Cable 49023

65. Screw 15024

66. Electric Switch Cover 15201

67. O'Ring 15023

68. Micro Switch 15018

69. Cylinder Screw 15025

70. Control Piston Complete 445321

71. Repair Set For Pressure Switch Mechanism 150093

72. Pressure Switch Complete without Mechanics 49054

73.1 Valve Housing Complete For 1152 TST 49052

73.2 Valve Housing Complete For 1152 TS 490521

74. Repair Kit For Unloader Valve 49055
